27inch Touch Monitor Embedded Panel PC PCAP Touch Tempered Glass Android Module Web Panel JLD-TPC-270 Embedded Display
Description
27inch Touch Monitor Embedded Panel PC PCAP Touch Tempered Glass Android Module Web Panel JLD-TPC-270
Summary
The 27-inch touchscreen monitor is a high-performance, versatile display designed to meet the demands of modern interactive applications. With its sleek design, advanced touch technology, and robust features, it is ideal for use in retail, hospitality, education, gaming, and industrial environments.The JLD-TPC-270 touch screen monitor capacitve touch display all in one machine is a versatile and compact 27-inch touchscreen all-in-one device designed for a wide range of applications. Seamless fit embedded installation, It features smart touch high definition screen, wide range of application. A sleek metal plate construction, available in black or white, and is lightweight at less than 5.2 kg. The device supports multiple installation modes, including embedded, wall-mounted, and desktop setups, making it highly adaptable to various environments.
Feature
--Embedded border
--Efficient heat dissipation
--Highlight
--Rich interface
--Rear shell anti slip
--Support I3/I5/I7,Celeron,J1900/N5095/5105,RK3568/RK3588
--Support SO-DIMM, support M-SATA,M2 Sata
--Standard 21.5inch HD display, capacitive touch screen, support dual display
--Standard with 4USB, 1LAN interface, can be extended 2USB and multi-specification COM interface
--Support1*Mini-PCIE (for WiFi)
--Support VESA bracket installation, wall mounted, desktop installation
Product Size
Support modification customization. power supply, serial port, etc can be modified:can add miltiple serial port. X86 solution with dual network ports.
Using the same kind of capacitive screen touch positioning technology with the IPAD, within 5ms speed response, far beyond the hunmanbody limit reaction speed 25ms, giving you an impeccable pleasure
Main parameters
| Model | JLD-TPC-270 | Pilot lamp | Power indicator light | Overall size | 654.89*393.3*68.3mm |
| Display | 27inch | Megaphone | Support | Display size | 596.89*335.3mm |
| TP type | Capacitive | Heat dissipation | Fanless | Color | Black/White |
| Resolution | 1920*1080 | Power consumption | ＜45W,Android lower | Material | Metal plate |
| Brightness | 300cd/㎡(500/700 optional) | Installation mode | embedded, wall-mounted, desktop | Weight | < 5.2kg |
| Viewing angle | 89°/89°/89°/89° (R/L/U/D) | Camera | 200W(500W/800W/1200W/2K/4K optional) | Certification | CE |
| Operating temperature | '-20℃-60℃ | ESD protection | ±4kV(contact),±8kV(air) | Warranty | One year |
| Storage temperature | '-25℃-70℃ | Accessories | Power adapter, wifi antenna, user manual |
Hardware and software(X86)
| Processor | Intel Bay Trail J1900(4 cores 4 threads) | Intel Gemini lake/N5095/N5105(4 cores 4 threads) |
| CPU frequency | 2.0GHZ,highest :2.41GHz | 2.0GHZ,highest:2.9GHz |
| OS | Windows 7 / Windows 10 / Linux Ubuntu 20.04 | Windows 7 / Windows 10 / Linux Ubuntu 20.04 |
| BIOS | AMI BIOS | AMI BIOS |
| Chipset | Intel® SOC | Intel® SOC |
| Image display | Intel ® HD Graphics integrated graphics | Intel ® UHD Graphics 600 |
| Ethernet | Realtek RTL8106E,10/100/1000Mbs self-adaptation | RLT8111H/8111G,10/100/1000Mbs self-adaptation |
| Sound effect | Realtek ALC662HD,support 8Ω5W | Realtek ALC269HD,support 8Ω5W |
| WiFi | Support WiFi 2.4G | Support WiFi 2.4G |
| Memory | Single DDR3L 1333MHz Max 8G | Single DDR4 2133/2400MHz Max 8G |
| Hard disk | M-SATA 128G | M-SATA 128G |
| Function | Bluetooth,4G,watchdog function | Bluetooth,4G,watchdog function |
| Front I/O | 1* switch(with LED); 2 * antenna; 2*COM(RS232or RS485 optional) | 1* switch(with LED); 2 * antenna; 2*COM(RS232or RS485 optional) |
| Rear I/O | 1 * DC IN interface 1 * HDMI interface 1 * VGA interface 2* USB3.0 interface 2 * USB2.0 interface 1 * LAN interface (Expandable to 2*LAN) 1* LINE-OUT interface 1* MIC-IN interface 2 * COM232 interface 2 * USB2.0 interface 1* M3 Earth bolt | 1 * DC IN interface 1 * HDMI interface 1 * VGA interface 2* USB3.0 interface 2 * USB2.0 interface 1 * LAN interface (Expandable to 2*LAN) 1* LINE-OUT interface 1* MIC-IN interface 2* COM232 interface 2 * USB2.0 interface 1* M3 Earth bolt |
| Power supply | DC12V | DC 12V |
| Power adapter | Input : 100-240V 50/60Hz ； output : 12.0V/5.0A | Input : 100-240V 50/60Hz ； output : 12.0V/5.0A |
Hardware and software(Arm)
| Processor | RK3568 quad core 64 bit Cortex-A55 | RK3588 quad core Cortex-A76+quad core Cortex-A55 |
| CPU frequency | Highest 2.0GHZ | Highest 2.4GHz |
| OS | Android11/Ubuntu20.04/Debain10 | Android 13/Ubuntu/Debain10 |
| GPU | ARM G52 2EE | ARM Mali-G610 MC4 |
| NPU | 1.0 TopS NPU Computility | 6 TopS NPU Computility |
| Ethernet | Support 10/1001000Mbps | Support 10/1001000Mbps |
| WIFI/BT | 2.4G/5.8G wireless WIFI;BT4.2/5.0 | 2.4G/5.8G wireless WIFI;BT4.2/5.0 |
| Sound effect | Stereo,support 8R8W | Stereo,support 8R8W |
| Memory | 2G/4G/8G LPDDR4/DDR4 optional(standard2G) | 2G/4G/8G LPDDR4 optional |
| Flash Memory | EMMC16G/32G/64G/128G optional | EMMC16G/32G/64G/128G optional |
| Function | 4G,watchdog | 4G,watchdog |
| Front I/O | 1* switch(with LED); 2 * antenna; 2*COM(RS232or RS485 optional) | 1* switch(with LED); 2 * antenna; 2*COM(RS232or RS485 optional) |
| Rear I/O | 1* DCIN interface 1 * LAN interface 2 * USB3.0 interface 1 * HDMI interface 1 * TF卡 interface 1 * LINE-OUT interface 2 * RS232 interface 2 * USB2.0 interface 1* M3 Earth bolt | 1 * DC IN interface 1 * HDMI-IN interface 1 * HDMI-OUT interface 2 * USB2.0 interface 1* USB3.0 interface 1* Type-C interface 2 * LAN interface 1 * TF卡 interface 1 * LINE-OUT interface 2 * COM232 interface 2 * USB2.0 interface 1* M3 Earth bolt |
| Power supply | DC 12V~24V | DC 12V~24V |
| Power adapter | Input : 100-240V 50/60Hz ； output : 12.0V/5.0A | Input : 100-240V 50/60Hz ； output : 12.0V/5.0A |
Multiple Installation
Size optional
| Size | Resolution | Screen Ratio | Touch type |
| 18.5inch | 1920*1080 | 16:9 | Capacitive |
| 21.5inch | 1920*1080 | 16:9 | Capacitive |
| 23.8inch | 1920*1080 | 16:9 | Capacitive |
| 27inch | 1920*1080 | 16:9 | Capacitive |
| 32inch | 1920*1080 | 16:9 | Capacitive |
| 43inch | 1920*1080 | 16:9 | Capacitive |
| 55inch | 1920*1080 | 16:9 | Capacitive |
Application:
Medical equipment
Self-service
Medical testing
Workshop equipment
CNC cabinet
Vending machine
Kiosk information platform
Monitoring center
Certificate
Our Services:
1.One-stop Solution:
We provide PCB design, manufacturing & assembly one-stop service.
2.Liability:
All products are 100% tested for reliabilities before shipment.
3.Quick-turn Service:
Quickest delivery 48hrs, quick response.
4.Full Qualification:
UL,ISO9001 Certified.
5.Professional Support, Advanced Technique:
100% free professional technical support
6.Flexibility:
No MOQ,both QTA (quick turn around) production and normal production can meet your leadtime.
Warranty
1. All products have been strictly Quality Checked in house before packing.
2. All products have been well packed before shipping.
3. One year warranty is provided for all models. We will bear maintenance cost during warranty.
4. Good quality control, 1-3 years warranty.
FAQ
Q1. Can I have a sample order for touch screen monitor?
A: Yes, we welcome sample order to test and check quality with your equipment. Customized development PCBA are available well.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than
Q3. Do you have any MOQ limit for trial order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for PCBA motherboard?
A: Firstly let us know your requirements or application.Secondly We quote according to your requirements or our suggestions.Thirdly customer confirms the samples and places deposit for formal order.Fourthly We arrange the production.
Q6. Is it OK to print my logo on PCBA motherboard product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 1-3 years warranty to our products.
Any inquiry, please leave message to us!
